Automatic Capsule Counting Machine 16L Hopper 10-45 Bottles/Min

인증
중국 Hangzhou SED Pharmaceutical Machinery Co.,Ltd. 인증
중국 Hangzhou SED Pharmaceutical Machinery Co.,Ltd. 인증
고객 검토
 나는 우리의 분무 건조기, 고속 건조를 위한 정확한 분무기를 선택하는 당신의 노력 전부를 당신을 감사하고 싶으면. 분무기, 습기의 95%-98%를 통해서 분무화 후에 많게 증가시킨 고열 기류에서 원료 액체의 표면만, 필요 두번 째 즉각 증발할 것입니다.

—— Fatih BÜYÜKEGEN

나는 진짜로 당신을의 당신 감사하는 방법을 입니다 나의 천사 모릅니다, 대단히 대단히 감사합니다. 이 것을 분쇄하는 최고 벌금은 다른 동일한 힘 기계 보다는 더 빠르 운영하기 쉽습니다 그리고 고쳐.

——  Hamid Doroudian

제가 지금 온라인 채팅 해요

Automatic Capsule Counting Machine 16L Hopper 10-45 Bottles/Min

Automatic Capsule Counting Machine 16L Hopper 10-45 Bottles/Min
Automatic Capsule Counting Machine 16L Hopper 10-45 Bottles/Min Automatic Capsule Counting Machine 16L Hopper 10-45 Bottles/Min

큰 이미지 :  Automatic Capsule Counting Machine 16L Hopper 10-45 Bottles/Min

제품 상세 정보:
모델 번호: SED-8SP

Automatic Capsule Counting Machine 16L Hopper 10-45 Bottles/Min

설명
호퍼 볼륨: 16L 용량: 10-45 병/분
10-45 병/분: (조정할 수 있는) 2-9999pcs/bottle 병 크기: 직경 ≤100mm, 높이 ≤180mm
컨베이어 벨트 너비: 114mm 압축 공기: 0.6MPA 5L/분
전압: 220V/50Hz/60Hz 전체적인 차원 (L*W*H): 1920*1360*1730mm
강조하다:

automatic capsule counting machine with 16L hopper

,

capsule counting machine 10-45 bottles per minute

,

high-speed automatic capsule counter

Automatic Capsule Tablet Counting Machine for Candy Pill Packing
Machine Introduction
This updated counting machine features quick material interchangeability for multiple applications. Designed with high-speed operation and efficient hygiene functions, it significantly reduces labor requirements. The machine offers fast and easy installation to maximize productivity, particularly suited for counting and filling soft candies and sticky-textured materials.
Working Principle
The bottle blocking device on the conveyor belt positions containers for filling. Materials enter the counting device through vibrating corrugated plates, where photoelectric sensors perform accurate counting before loading into bottles at the filling position.
Technical Parameters
Model Name SED-8SP
Application Hard capsule (000-5#), Soft Gelatin capsule, Pills, Chewing gum, tablet, and solid objects (Diameter: 5.5-22mm)
Hopper Volume 16L
Capacity 10-45 bottles/min
Filling Quantity 2-9999pcs/bottle (adjustable)
Bottle Size Diameter ≤100mm, Height ≤180mm
Conveyor Belt Width 114mm
Compressed Air 0.6Mpa, 5L/min
Voltage 220V/50HZ/60HZ
Overall Dimension (L*W*H) 1920*1360*1730mm
Key Features
  • 3-stage adjustable vibration: Precisely controls capsule output speed
  • Strong compatibility: Counts tablets (including special-shaped), capsules, soft capsules (transparent/opaque), and pills
  • Quick material change: No mold changes required when switching counting objects
  • 8-channel vibration: Ensures even material discharge without damage
  • Hygienic design: Easy cleaning with removable vibration plates
  • Anti-dust system: Patented photoelectric sensor technology maintains stable operation in dusty conditions
  • Precision counting: Photoelectric sensors ensure accurate bulk counting
  • Smart detection: Includes no-bottle-no-counting, self-diagnosis, and jam detection functions
  • User-friendly: Touch screen interface for simplified operation
